Modify Menu: Array

in Ezcad Manual, , ,

Click “Array”, we can see the figure.

Array

Rectangle: The graph according to rectangle array

Circle: The graph according to circle array.

Array re

: Set array’s row as marking precedence.

: Bidirectional array.

Array num: The row number.

Array num: The column number.

Array: The space between two objects on X direction.

Array: The space between two objects on Y direction.

Calculate by offset distance: The space of the graphs is calculated by offset distance.

Calculate by graph distance: The space of the graphs is calculated by graph distance.

If we select the array type is “Circle”, we can see the figure:

array circle
array circle 2

: The graphs array is clockwise or anticlockwise.

Array number: The graph number.

Radius: The radius of the circle.

StartAngle: The angle between the starting graphs of the circle.

Angle: The angle between two graphs.
